  [Camouflage of Vehicles]



SHADOWS

[FIGURE 25. A vehicle can be identified merely by the shadow it casts.]

FIGURE 25.—A vehicle can be identified merely by the shadow it casts.

    There are two kinds of shadows to look out for in camouflage.

    One is the concealing shadows cast by objects or formations on the ground. From the air these shadows appear so dark that a vehicle parked within them has a good chance of being unnoticed. Other camouflage measures should often be taken, but making use of these shadows is an important primary step in concealment. In the northern hemisphere, the north side of an object higher than the vehicle is the best side to park on, and the east and west sides are each dangerous for half a day.

    The other kind of shadow to look out for is that cast by the vehicle. This reveals and identifies a vehicle and must be hidden. Hiding is accomplished either by parking in the shadow of an object—if the shadow is large enough to encompass the vehicle—or by parking on the sunny side of the object, if the shadow is too small. Watch out not only for the over-all shadow of the vehicle but also for the smaller shadow areas contained within the vehicle itself, such as the shadow line of the truck body, in and around the cab, underneath the fenders, within the wheels, and in the open back of the cargo space. A vehicle is easily recognized by these small shadows even when its main outlines are obscure. They must be broken up or hidden by natural or artificial materials.


[FIGURE 26. If you must park on a road, watch that shadow.  Park, as the foremost truck has done, so that the shadow is thrown into an irregular ditch or upon a bush. Do not park, as the rear truck is parked, so that the shadow of the vehicle falls on a smooth surface.]

FIGURE 26.—If you must park on a road, watch that shadow. Park, as the foremost truck has done, so that the shadow is thrown into an irregular ditch or upon a bush. Do not park, as the rear truck is parked, so that the shadow of the vehicle falls on a smooth surface.

[FIGURE 27 (1) and (2). Right. Morning or late afternoon shadows are long and protective.  Park your vehicle in them.  But remember that shadows move. Be sure you move with them.] [FIGURE 27 (1) and (2). Wrong. Morning or late afternoon shadows are long and protective.  Park your vehicle in them.  But remember that shadows move. Be sure you move with them.]

FIGURE 27 (1) and (2).—Morning or late afternoon shadows are long and protective. Park your vehicle in them. But remember that shadows move. Be sure you move with them.
